4. Remove two screws (callout 3) and remove the lower flatbed ribbon cable guide (callout 4).
3
4
Figure 5-84 Removing the power supply (3 of 6)
NOTE: When reinstalling the ribbon cable, make sure that you feed it through the ferrite.
5. Remove five screws (callout 6) and remove the right keyboard tray guide.
6
Figure 5-85 Removing the power supply (5 of 6)
100 Chapter 5 Removal and replacement ENWW
