SECO-LARM USA SD-994C Door User Manual



Series Electric Door Strikes
1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: 1.949.261.7326
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
SD-995C
SD-995C24
SD-994C
SD-994C24
For Metal Doors, 12VDC
For Metal Doors, 24VDC
For Wood Doors, 12VDC
For Wood Doors, 24VDC
Convert cylindrical lock sets to electronic access
control locking systems.
Use on virtually any cylindrical door locking system.
Use with an optional digital keypad such as
SECO-LARM’s SK-983A or SK-983A100 for keyless
high security.
Symmetrically-shaped. Reversible for
right-hand or left-hand doors.
Shallow design for use with most doors.
Powered by a solenoid, not a buzzer coil.
Stainless steel lip (keeper) for strength and long life.
Jaw strength — 2,000 lbs.
Non-polarized connection. Wires can be reversed.
Tested to 1 million cycles.
Optional Lip-Extension Kits:
1" Lip Extension
2" Lip Extension
SD-995C-LE25:
SD-995C-LE50:
SD-994C /
SD-994C24
SD-995C /
SD-995C24
Dimensions:
12VDC
250mA
____
24VDC
____
150mA
SD-995C /
SD-994C
SD-995C24 /
SD-994C24
Current
®®
1-3/8"
(35mm)
1/8"
(3mm)
1-3/4" (45mm)
1-7/16"
(36mm)
11/16"
(18mm)
1-11/16" (43mm)
1-1/4"
(32mm)
5/8"
(16mm)
4-7/8"
(124mm)
4-1/8"
(105mm)
3-3/8"
(86mm)
1-3/4"
(45mm)
7-5/16"
(186mm)
7-15/16"
(202mm)
11/16"
(17mm)
ANSI-sized
