25-EN
1
Press SOURCE/ to switch to the USB AUDIO
mode.
The mode will change every time the button is pressed.
TUNER DISC USB AUDIO iPod*
1
/AUX+*
2
BT AUDIO*
3
AUX*
4
TUNER
*
1
Only when the iPhone/iPod is connected and AUX+ SETUP is set to
OFF, refer to
“Setting the AUX+ SETUP Mode” (page 20).
*
2
Displayed only when AUX+ SETUP is set to ON, refer to “Setting the
AUX+ SETUP Mode” (page 20).
*
3
Only for CDE-101R/CDE-101RM/CDE-102Ri and BT IN is set to BT
ADAPTER. Refer to
“Bluetooth Setting” (page 19).
*
4
Refer to “Using the Front AUX Input Terminal (CDE-102Ri/CDE-
103BT/CDE-104BTi only)” (page 18).
2
To pause playback, press / /ENT.
Pressing / /ENT again will resume the playback.
• The root folder is displayed as “ROOT” in the Folder Name Search
mode.
• When a search is made in the USB mode, any song being played back
will be stopped.
• This unit plays back files in the USB memory with the same controls
and modes as playback of CDs containing MP3/WMA/AAC. For
details, refer to
“CD/MP3/WMA/AAC” on pages 11 to 15.
• Before disconnecting USB memory, be sure to change to another
source or set to pause.
• The playback time may not be correctly displayed when a VBR
(Variable Bit Rate) recorded file is played back.
USB memory Connection (Optional)
Connect USB memory
1
Open the cover of the USB Connection Terminal.
2
Connection the USB memory directly to the USB
Connection Terminal, or via the USB cable.
Remove USB memory
1
Carefully, pull out the USB memory from the USB
cable or the USB Connection Terminal.
2
Close the cover of the USB Connection Terminal.
• Change to a source other than the USB memory mode, then remove
the USB memory. If the USB memory is removed in the USB memory
mode, data may be damaged.
• When removing USB memory, pull it out straight.
• If sound is not output or USB memory is not recognized even when
USB memory is connected, remove USB memory once, and then
connection it again.
• Route the USB cable away from another cables, etc.
• After removing the USB memory, close the cover of the USB
Connection Terminal to prevent dust or foreign objects from entering
and causing a malfunction.
About MP3/WMA/AAC File of USB
Memory
Playing back MP3/WMA/AAC
MP3/WMA/AAC files are prepared, then stored to a USB
memory. This unit can recognise at least 100 folders and
100 files per folder stored in USB memory. Playback may not be
performed if a USB memory exceeds the limitations described
above.
Do not make a file’s playback time more than 1 hour.
Media supported
This device can play back USB memory.
Corresponding File Systems
This device supports FAT 12/16/32 for USB memory device.
This unit USB Connection Terminal
USB memory
(sold separately)
USB memory
(sold separately)
Cable (sold
separately)
or
