-8-
(;838=60B4GC4=B8>=B – These extensions
provide extra workpiece support and are espe-
cially useful when cutting long workpieces.
0B4GC4=B8>=;0<?8=6!4E4AB – These
levers lock the base extensions at the desired
positions.
!4=6C7(C>?">34;>=;H – For repetitive
cuts of the same length. Can be moved to left
side, if desired.
DBC%>AC – The dust port can accommodate
the dust chute and dust bag or optional VAC004
Vacuum Hose Adapter, which accepts Bosch
35mm hoses.
4E4;!>2:!4E4A – The front-positioned bevel
lock lever locks the head assembly at the de-
sired bevel angle.
4E4;'0=64(4;42C>A =>1 – Allows selection
of the bevel range, 0° to 45° left, 0° to 45° right,
and complete range of 47° left to 46° right.
(;834'08;!>2: =>1 – The slide rail lock knob
locks the slide rails when you are not making
slide cuts and when you are transporting the saw.
(;834'08;B – Guide the head assembly when
making slide cuts.
;0<? %>B8C8>= >;4B – There are two (2)
holes (not shown) behind the fence for placing
the clamp.
&D82:2C8>=;0<?">34;>=;H – Pro-
vides fast clamping of workpiece.
,>A:?8424;0<?">34;>=;H – Pro-
vides fast clamping of workpiece.
>A3,A0? – Allows you to easily wrap up the
cord so it’s out of the way when transporting or
storing.
"D;C8%DA?>B4)>>;">34;>=;H – Used
for loosening/tightening the blade and for fence
adjustments.
"D;C8%DA?>B4P!Q,A4=27<<">34;
>=;H – Used for loosening/tightening the
blade.
