Attaching Peripherals
Step 6 After the workstation andIGX node interface have been setup, Cisco WAN Manager can
be started. After Cisco WAN Manager has started and the communication sockets are
active, the dsplan screen looks like this:
D2.cb1 LAN cisco IGX 8410 9.3 Feb. 27 2000 14:27 PST
Active IP Address: 192.187.207.21
IP Subnet Mask: 255.255.255.0
TCP Service Port: 5130
Default Gateway IP Address: 192.187.207.1
Maximum LAN Transmit Unit: 1500
Ethernet Address: 00.55.43.00.04.55
Control Socket - Ready
Base Socket Descriptor - 1
Open Socket Descriptor - 2
Last Command: dsplan
Next Command:
Note “Sockets” is the BSD UNIX name for connections between processes and
typically applies to network communication.
Note Before switchingon theCisco WAN Managerworkstation, referto theCisco WAN
Manager Operations publication.
