Setup Menu
These settings are used to provide the printer with information
necessary for printing. See “Setup menu” on page 2-22 for further
details.
Parallel Menu
These settings control communication between the printer and
the host computer when using a parallel interface. See “Parallel
menu” on page 2-24 for further details.
AUX1 Menu / AUX2 Menu
If the optional Type B interface has been installed, these settings
control the communication between the two units using this
interface. See the manual supplied with the interface for further
details.
LJ4 Menu
These settings control the fonts and symbol sets when the printer
is in LJ4 emulation mode. See “LJ4 menu” on page 2-25 for further
details.
Interface, Time Out, Standby, Lang, Printer Name, Y Toner,
M Toner, C To ner, K Toner, Page Count, SelecType Init
Speed, Bi-D, Buffer Size
Buffer Size
Font Source, Font Number, Pitch
*
, Height
*
, SymSet
**
, Form,
Source SymSet**, Dest SymSet**
* Depending on the font selected
**These settings depend on the font set installed.
