Configuring the printer Configuring the printer
3-11 3-12
- The bottom margin indicates the last print line. Going beyond this margin - Paper Exit (only for single sheet paper)
automatically initiates a form feed. The bottom margin is always set in steps It is possible to choose between STACKER and FRONT SIDE (manual front
of / ". insertion). The desired paper exit can be selected via operator panel or
1
6
The bottom margin can be set to a maximum of / ".
8
6
The above specifications are influenced by the settings in "Vertical Position" output with a keystroke on . That is a useful option when using
(see section "V.POS" in this chapter). automatic sheet feeding which could cause a paper jam. As opposed to
- Perforation Skip received.
- If PERF. SKIP is set to YES the printer starts to print after specified top
margin and stops printing before the bottom Margin. - Emulation
- If PERF. SKIP is set to NO the printer ignored the top and bottom margin Appendix D, E, and F). You can activate the following emulations:
and prints from the very first line to the very last. That means that on a - PHILIPS GP
standard 11" paper 66 lines are available for printing. - IBM PROPR.
- Paper Source - EPSON LQ / ESC/P2
The printer offers three input possibilities:
- TRACTOR (fanfold paper) Note: The selected Emulation will also be stored in the actual macro. With a
- Manual change of the macro (e.g. key , , or is pressed) it is
- ASF cassettes (optional), they can be accessed either individually or possible that the emulation will also be changed. Be careful: Do not
pooled in a specified sequence. Any combination or cassettes can be change the emulation within an application.
selected.
A corrective factor for the vertical positioning of the paper can be applied to When selecting a character set it can be further specified by the
each paper source and the Run-In-Sensor (see section VERT.POS.ADJ.). corresponding national variants.
Note: Please refer to chapter 7, Technical Data, for detailed media Detailed print samples are found in Appendix B and the Character Set
specifications. Tables in Appendix C.
software.
Note: If you choose the paper exit FRONT SIDE/KEY you have to confirm each
feeding automatically the ASF will only feed after a keystroke has been
The emulation determines the set of commands available for the printer (see
- IBM PROPR.AGM
- Character Set
If a different macro is selected the default character set may change,
e.g. - PHILIPS GP emulation has the character set NV-2.5 as default.
- IBM PROPR. emulation has the character set IBM SET 2 as default.
- EPSON / EDC/P2 emulation has the character set EPSON EXT.GCT
as default.
