26
Point
- To install an expansion card, set up the PC, turn off the power, and install the expansion card.
- The first to fourth white slots from the top are for PCI cards.
- Only a half-size expansion card can be installed in the first slot from the top.
- When an expansion card using a serial port such as a modem card is installed, change the
duplicated serial port to "Not used" in the BIOS setup.
WARNING
● To prevent electric shock, before installing and removing expansion cards,
turn off the PC and connected units and unplug power cords from respective
outlets.
● To prevent electric shock, fire, and/or malfunction, install only Fujitsu brand
expansion cards in the PC.
CAUTION
● To prevent injury, when installing and removing expansion cards, remove
screws only from specified locations.
Electric shock
Injury
3 Installing Expansion Cards
This section explains how to install expansion cards, which extend the range of the features of
your PC.
PCI bus
PCI bus
