Item Values Explanation
TRAY 1 SIZE List of available media
sizes for tray 1
Use this item to set the value to correspond with the media
size that is currently loaded in tray 1. See
Supported media
sizes for a list of available sizes. The default setting is ANY
SIZE.
ANY SIZE: If both the type and size for tray 1 are set to ANY,
the printer will pull media from tray 1 first if media is loaded in
the tray.
A size other than ANY SIZE: The printer does not pull from
this tray unless the type or size of the print job matches the
type and size that is loaded in this tray.
TRAY 1 TYPE List of available media
types for tray 1
Use this item to set the value to correspond with the type of
media that is currently loaded in tray 1. See
Supported media
sizes for a list of available types. The default setting is ANY
TYPE.
ANY TYPE: If both the type and size for tray 1 are set to
ANY, the printer will pull media from tray 1 first if the media is
loaded in the tray.
A type other than ANY TYPE: The printer does not pull from
this tray.
TRAY 2 SIZE List of available media
sizes
The tray automatically detects the media size based on the
media-size wheel setting in the tray. The default setting is
either LTR (letter) for 100 V engines or A4 for 200 V engines.
TRAY 2 TYPE List of available media
types
Sets the value to correspond with the media type that is
currently loaded in tray 2. The default setting is ANY TYPE.
TRAY [N] UNIT OF MEASURE
X DIMENSION
Y DIMENSION
This item appears only if a tray is set to a custom size.
UNIT OF MEASURE: Use this option to select the unit of
measure (INCHES or MILLIMETERS) to use when you set
custom paper sizes for the specified tray.
X DIMENSION: Use this item to set the measurement of the
width of the paper (measurement from side to side in the
tray). The options are 3.0 to 12.28 INCHES or 76 to 312 MM.
Y DIMENSION: Use this item to set the measurement of the
length of the paper (measurement from front to back in the
tray). The options are 5.0 to 18.5 INCHES or 127 to 470 MM.
After the Y DIMENSION value is selected, a summary screen
appears. This screen contains feedback that summarizes all
of the information that was specified on the previous three
screens, such as TRAY 1 SIZE= 8 x 16 INCHES, Setting
saved.
