Menu 2-9
Menu The menu has these main sections:
◆ Calibrate Printer (see below)
◆ Printer Settings (page 2-10)
◆ Maintenance (page 2-14)
◆ Service Printer (page 2-15)
◆ User Diagnostics (page 2-15)
◆ Warnings & Actions (page 2-16), shown in Expert Messages
Mode only
This section explains each of the functions on the printer menu.
See “Menu Tree” on page 2-17 for a listing of all menu options.
Calibrate Printer For details on these options, see Chapter 4, Calibrating the
Printer.
◆ Media Feed — eliminates banding between print swaths
(“stitch banding”) by calibrating media advance. See
“Media Feed” on page 4-6 for instructions.
◆ Manual Calibrations — allows you to calibrate the printer
visually, without the printer’s digital imaging sensor. Inaccu-
rate judgments by the operator during these tests could
result in substandard output. See “Manual Calibrations” on
page 4-8 for instructions.
◆ Manual Bidi Registration
◆ Manual X Head Registration
◆ Manual Jet Mapping — the manual version of AutoJet
◆ Jet Status Lines — prints the Manual Jet Mapping pat-
tern without running the calibration
◆ Default Registration Data
◆ Auto Calibrations — see “Auto Calibrations” on page 4-20
for instructions.
◆ Auto Bidi Calibration — ensures that every working jet
fires a pixel at precisely the same location, in both direc-
tions of travel
◆ Auto H2H Calibration — aligns the printheads relative to
each other
◆ AutoJet Calibration — locates and substitutes missing jets
for working jets
◆ Full AutoSet — runs AutoJet and AutoBiDi in sequence
