1–2 Maintenance and Service Guide
Product description
Panels 15.6-inch, WXGA panel (1366 × 768)
Typical brightness 220 nits
Webcam Low profile VGA camera
Fixed (no tilt)
Activity LED
640 × 480 by 24 frames per second
Memory 2 customer-accessible/upgradable memory module slots
Supports dual-channel memory
PC3, 1066 MHz front side bus (FSB), DDR3
Supports up to 8 GB of system RAM in the following configurations:
■ 8192-MB total system memory (4096 MB × 2, dual-channel)
■ 6144-MB total system memory (2048 MB × 1 + 4096 MB × 1)
■ 4096-MB total system memory (2048 × 2, dual-channel)
■ 3072-MB total system memory (2048 × 1024)
■ 2048-MB total system memory (1024 × 2, dual-channel)
■ 2048-MB total system memory (2048 × 1)
■ 1024-MB total system memory (1024 × 1)
Hard drives Supports all Serial ATA (SATA) 9.5-mm, 6.35-cm (2.50-inch) hard drives
Supports up to 2 hard drives
Support for HP ProtectSmart Hard Drive Protection
Supports the following drives:
■ 500-GB, 7200-rpm
■ 500-GB, 5400-rpm
■ 320-GB, 7200-rpm
■ 320-GB, 5400-rpm
■ 250-GB, 7200-rpm
■ 250-GB, 5400-rpm
Optical drives Fixed (removal of 1 screw required)
12.7-mm tray load
Serial ATA
Supports the following drives:
■ DVD±RW and CD-RW SuperMulti Double-Layer (DL) Combo Drive with LightScribe
■ Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer (DL) Drive
Microphone 2 omnidirectional microphones, dual-array with appropriate software (supports beam
forming, echo cancellation, and noise suppression)
Audio HD Audio (IDT)
Supports Microsoft® Premium Requirements
Modem 56K V.92 data/fax modem
Supports all worldwide certification requirements
Ethernet Integrated 10/100/1000 network interface card (NIC) (Discrete models)
Wireless Integrated wireless local area network (WLAN) by way of wireless module:
2 wireless antennas built into display assembly
Category Description
