Configuration Menu 126
The following table describes the Network Filter Configuration Menu options.
Table 127 Network Filter Configuration Menu options
Command Description
addr <IP address>
Sets the starting IP address for this filter. The default address is 0.0.0.0
mask <IP subnet mask>
Sets the IP subnet mask that is used with /cfg/l3/nwf/addr to define the
range of IP addresses that will be accepted by the peer when the filter is
enabled. The default value is 0.0.0.0
enable
Enables the Network Filter configuration.
disable
Disables the Network Filter configuration.
delete
Deletes the Network Filter configuration.
current Displays the current the Network Filter configuration.
Route Map configuration
Command: /cfg/l3/rmap <1-32>
[IP Route Map 1 Menu]
alist - Access List number
aspath - AS Filter Menu
ap - Set as-path prepend of the matched route
lp - Set local-preference of the matched route
metric - Set metric of the matched route
type - Set OSPF metric-type of the matched route
prec - Set the precedence of this route map
weight - Set weight of the matched route
enable - Enable route map
disable - Disable route map
delete - Delete route map
current - Display current route map configuration
NOTE: This menu is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
Routing maps control and modify routing information. The map number (1-32) represents the routing map you wish to
configure.
The following table describes the Route Map Configuration Menu options.
Table 128 Route Map Configuration Menu options
Command Description
alist <1-8>
Displays the Access List menu.
aspath <1-8>
Displays the Autonomous System (AS) Filter menu.
ap <AS number> [<AS number>] [<AS
number>]|none
Sets the AS path preference of the matched route. One to three path
preferences can be configured.
lp <0-4294967294>|none
Sets the local preference of the matched route, which affects both
inbound and outbound directions. The path with the higher preference is
preferred.
metric <0-4294967294>|none
Sets the metric of the matched route.
type 1|2|none
Assigns the type of OSPF metric. The default is type 1.
• Type 1—External routes are calculated using both internal and
external metrics.
• Type 2—External routes are calculated using only the external
metrics. Type 2 routes have more cost than Type 2.
• none—Removes the OSPF metric.
prec <1-256>
Sets the precedence of the route map. The smaller the value, the higher
the precedence. Default value is 10.
weight <0-65534>|none
Sets the weight of the route map.
