When running IP over FC, these management tools must be run on both the Fibre Channel
host and the switch and must be supported by the Fibre Channel host driver. For a list of
Fibre Channel hosts supported by the 4Gb SAN Switch, contact your HP representative.
Table 8 4Gb SAN Switch management features
Manag ement tool
Out-of-band support
In-band support
CLI —Runuptotwoadmin
sessions and four user
sessions simultaneously. For
more information, refer to
the latest version of the HP
StorageWorks Fabric OS
administrator guide and
the Fabric OS command
reference guide.
Ethernet or serial connection
IP over FC
Advanced Web Tools —
For information, refer to
the latest version of the
Fabric OS Web Tools
administrator’s guide.
Ethernet connection
IP over FC
Standard SNMP
applications —For
information, r efer to t he
latest version of the Fabric
OS MIB reference guide.
Ethernet connection
IP over FC
Management Server —For
more information, refer to
the latest version of the HP
StorageWorks Fabric OS
administrator guide and
the Fabric OS command
reference guide.
Ethernet connection SMI-S compliant
management program
You can connect a management station to one switch via Ethernet while m anaging other
switches connected to the first switch via FC. To do so, set the FC gatew ay address of
each of the other switches to be managed to the FC IP address of the first sw itch .
The gateway address of the first switch should be set to whatever the gateway address is
for the subnet on which the first switch resides. See Table 9.
