Spare part
number
Description
646212-001 150-W AC adapter
652637-001 System board for use with dual-core processors in all countries and regions except Russia and the People's
Republic of China (does not include Alcor chip upgrade; includes replacement thermal material and VGA
support bracket)
652638-001 System board for use with quad-core processors in all countries and regions except Russia and the
People's Republic of China (does not include Alcor chip upgrade; includes replacement thermal material
and VGA support bracket)
652639-001 Display bezel for use on computer models with a webcam
652640-001 Display bezel for use on computer models without a webcam
652641-001 Display cable for use on computer models without DreamColor displays (includes microphone and webcam
connector)
652646-001 Display hinges (includes left and right hinges)
652647-001 Display latch with hook
652648-001 Service access cover
652649-001 Base enclosure
652650-001 RTC battery
652652-001 Top cover for use on computer models that include a fingerprint reader (includes TouchPad button and
bracket)
652654-001 Power button board
652656-001 VGA port
652657-001 Display hinge covers (for use on computer models without DreamColor displays)
652658-001 Display hinge covers (for use on computer models with DreamColor displays)
652659-001 Webcam module
652660-001 Microphone board
652661-001 Screw Kit
652662-001 Cable Kit (for information about Cable Kit contents, see
Cable Kit on page 30.
652663-001 Rubber Kit (includes rubber feet and rubber screw covers)
652664-001 Plastics Kit (for information about Plastics Kit contents, see
Plastics Kit on page 29.
652665-001 Function button board
652666-001 Logo nameplate with light; for use on the back cover of the LCD
652668-001 Audio/USB 3.0 board (select models only)
652669-001 Speakers
652670-001 Secure Digital (SD) card/USB 2.0 assembly board
652672-001 Smart card reader (includes door and cable)
652673-001 NVIDIA Quadro 1000M graphics card (includes replacement thermal material)
652674-001 NVIDIA Quadro 2000M graphics card (includes replacement thermal material)
Sequential part number listing 37
