FRU Removals and Replacements
1070 Keyboard
Battery Pack (1030)
Hard Disk Drive (1040)
CD-ROM Drive or Diskette Drive (1050)
Keyboard Assembly (1060)
Note
When you tear off the insulator in step 1, do it gently
for it is reused.
2
1
4
3
2
Bottom view
4
Step Screw (Quantity) Color Torque
2 M2.5 × 3 mm,
nylon-coated (6)
Yellow 4 kgcm
74
