Safety
A
A
To Permanent Connection
of Building Ground
(Protective Earthing)
Controller
Expansion
B
B
B
B
A
Detail
Screw M5
Lock Washer
Star Washer
Figure 0-3. Ground Wire Connection Between Attached Controller Expansions
xxii 3745 Models 130 to 17A: MIP
