Operator’s Manual 31
Specications
ITEM SPECIFICATION
AC-1000E AC-1000E-C AC-1500E AC-1500E-C
Water Pump ......................................... 2.0 GPM 2.0 GPM 2.0 GPM 2.0 GPMC
(7.6 L/min) (7.6 L/min) (7.6 L/min) (7.6 L/min)
Pressure at Pump Manifold.................. 1000 PSI 1000 PSI 1500 PSI 1500 PSI
(68.9 Bar) (68.9 Bar) (103.4 Bar) (103.4 Bar)
Electric Motor :
Horsepower .......................................... 1.5 1.5 2.0 2.0
Volts ..................................................... 120 120 120 120
Amps .................................................... 15.0 15.0 20.0 20.0
Phase ................................................... Single Single Single Single
Hertz .................................................... 60 60 60 60
Electric Cord ........................................ 35 ft. w/ GFCI 35 ft. w/ GFCI 35 ft. w/ GFCI 35 ft. w/ GFCI
Discharge Hose .................................. 25 ft. x 3/8 in. 25 ft. x 3/8 in. 25 ft. x 3/8 in. 25 ft. x 3/8 in.
(7 m x 6.4 mm) (7 m x 6.4 mm) (7 m x 6.4 mm) (7 m x 6.4 mm)
Nozzle Size .......................................... 1.40 mm 1.40 mm 1.25 mm 1.25 mm
RECORD SERIAL NUMBER
Write you model number, machine serial number (see
serial number tag (A) in illustration) and date of purchase
in the spaces provided below. Your dealer needs this
information when ordering parts.
Model No. ______________________________________________
Machine Serial No. _______________________________________
Date of Purchase ________________________________________
(To be lled in by purchaser)
POWER WASHER
MODELNO.
SERIALNO.
DATE CODE
Made in U.S.A.
34-0075
MAX. GPM
MAX. PSI
NOZZLE SIZE
HP / PHASE
AMPS
VOLTS / HZ
MAX.INLETWATER
TEMPERATURE,°F
Conforms to ULStd. 1776
