KRAMER: SIMPLE CREATIVE TECHNOLOGY
VP-725XLA Communication Protocol
60
Control Type
Function Parameter Description
Set
Get
2: 1/9 (for Get Command)
3: 1/4 (for Get Command)
Note: For set function command, parameter will
be ignore
0 - 175 N/A
Hot key Master Audio, same as remote control /
Keypad
- Master Audio of SELECT
0 - 176 N/A
Hot key Scaler, same as remote control / Keypad
- Scaler of SELECT
0 - 177 N/A
Hot key Audio Group, same as remote control /
Keypad
- Audio Group of SELECT
0 - 178 N/A
Hot key Video Group, same as remote control /
Keypad
- Video Group of SELECT
0 1 179
10: Audio Level = Master In
11: Audio Level = Master Out
12: Audio Level = Mic In
13: Audio Level = Off
Hot key Audio Level , same as remote control /
Keypad
- Audio Level
Note : parameter must be in the range of
10 ~ 13, or it will have no effect
0 - 180 N/A
Hot key Override, same as remote control /
Keypad
- Override
0 - 181 N/A
Hot key Talk Over, same as remote control /
Keypad
- Talk Over
0 - 182 N/A
Hot key Mix, same as remote control / Keypad
- Mix
0
-
183
N/A
VGA Group Output Volume Increase
0
-
184
N/A
VGA Group Output Volume Decrease
0
-
185
N/A
HDMI Group Output Volume Increase
0
-
186
N/A
HDMI Group Output Volume Decrease
0
-
187
N/A
COMP Group Output Volume Increase
0
-
188
N/A
COMP Group Output Volume Decrease
0
-
189
N/A
YC Group Output Volume Increase
0
-
190
N/A
YC Group Output Volume Decrease
0
-
191
N/A
CV Group Output Volume Increase
0 - 192 N/A CV Group Volume Decrease
0 - 193 N/A MASTER Group Output Volume Increase
0 - 194 N/A MASTER Group Output Volume Decrease
0 1 195 -100 ~ +100 HQV Color Setting - Red
0 1 196 -100 ~ +100 HQV Color Setting - Green
0 1 197 -100 ~ +100 HQV Color Setting - Blue
0 1 198 -100 ~ +100 HQV Color Setting - Cyan
0 1 199 -100 ~ +100 HQV Color Setting - Magenta
0 1 200 -100 ~ +100 HQV Color Setting - Yellow
0 1 201
0 : DVD/Normal
1 : PC/Bypass
HDMI1 Switching Behavior, not available for old
HW versions
0 1 202
0 : DVD/Normal
1 : PC/Bypass
HDMI2 Switching Behavior, not available for old
HW versions
0 1 203
0 : DVD/Normal
1 : PC/Bypass
HDMI3 Switching Behavior, not available for old
HW versions
0 1 204
0 : Normal
1 : Bypass (Win7)
HDMI4 Switching Behavior, not available for old
HW versions
