Parameters
Parameter Length Description
Type 1 File type (0:Font File, 1:Bitmap)
refID 1 Reference ID number
Description Download a specified file from the filesystem. The first 4 bytes will be
the length of the file (LSB to MSB) followed by the data contained in the
file.
Remembered No
11.7 Moving a File
Syntax
Hexadecimal 0xFE 0xB4 [oldT] [oldID] [newT] [newID]
Decimal 254 180 [oldT] [oldID] [newT] [newID]
Parameters
Parameter Length Description
oldT 1 Old file type
oldID 1 Old file ID
newT 1 New file type
newID 1 New file ID
Description This command can be used to move a file to a new file ID, or correct the
type of a file that was uploaded incorrectly. The command first checks to
see if there is a file identified by [oldT] and [oldID]. If it does exist, and
there is no file already with the desired type and ID, the ID and type of
the old file will be changed to [newT] and [newID] respectively.
Remembered Always
12 Data Security
12.1 Introduction
Ensuring that your GLK24064-25 display’s exactly what you want it to can be the difference between a
projects success and failure. This is why we incorporate features such as Data Lock into the GLK24064-25.
With this new feature you now are in control over of how and when settings will be changed so there is no
need to worry about the module acting exactly like you expected it to because all the settings may be locked
and remembered for the next power up.
Matrix Orbital GLK24064-25 47
