Install SpectraLink 6000 System
Connect multi-unit systems
Use the following procedure to connect multiple MCUs.
1. Mount the MCUs side by side.
2. Connect the IPC cable from the
OUT port of the first unit to the IN
port of the adjacent unit. Repeat until all units are connected, as
shown in the following illustration.
Multi-Unit SpectraLink 6100 MCUs
No IPC cable is connected to the IN port of the first unit. An Open
Applications Interface (OAI) Telephony Gateway may be
connected to the OUT port of the last unit.
