Print Speed Limits
75
Use this formula to determine printer speed in relation to bar code
height:
By changing the Min. Code Height, the printer and slew speeds will
be changed automatically.
To change the Min. Code Height:
1. Press to take the printer offline and place the printer in
Menu mode.
2. If necessary, press ↓ and
↵ at the same time to unlock the
↵ key.
3. If necessary, press until VALIDATOR displays.
4. Press ↓ until Min. Code Height displays.
5. Press + or – to scroll through the choices: 0.13 to 1.00 inches in
0.01 inch increments. The default is 0.30 inches.
6. Press
↵ to select the desired value. The printing and slew
speeds will be changed after
↵ is pressed.
7. Press ↓ and
↵ at the same time to lock the ↵ key, then press
PAUSE to take the printer offline.
8. Press PAUSE again to put the printer online.
To set the printer speed manually:
1. Press to take the printer offline and place the printer in
Menu mode.
2. If necessary, press ↓ and
↵ at the same time to unlock the
↵ key.
3. Press until MEDIA CONTROL displays.
4. Press ↓ until Print Speed displays.
5. Press + or – to scroll through the choices.
6. Press
↵ to select the desired value.
7. Press ↓ and
↵ at the same time to lock the ↵ key, then press
PAUSE to take the printer offline.
8. Press PAUSE again to put the printer online.
Bar Code Height In Inches
0.030
Maximum Printer Speed In
Inches Per Second
=
.
.
.
.
.
.
.
.
.
.
.
.
