SPECIFICATIONS
For information on power requirements, power consumption, dimensions, weight, and other specifications that are
common to all features of the machine, refer to operation manual for copier.
*1 Transmission speed is for an 8-1/2" x 11" document with approximately 700 characters at standard resolution (8x3.85
lines/mm) sent in high speed mode (33.6 kbps (JBIG) or 14.4 kbps (MMR)). This is only the time required to transmit the image
information; the time required to send protocol signals is not included. Actual transmission times will vary depending on the
contents of the document, the receiving machine type, and telephone line conditions.
*2 Image memory can be expanded by installing the optional fax expansion memory (8 MB).
*3 The length varies depending on the scanning resolution and the width of the original. At "FINE" resolution, the maximum size
is 11" (W) x 39.3" (L) (297 mm (W) x 1000 mm (L) ). ("ORIGINALS" (p.9))
Applicable telephone line Public switched telephone network
Compression method MH, MR, MMR, JBIG (MMR and JBIG during Super G3 transmission)
Transmission modes Super G3, G3 (the machine can only send faxes to and receive faxes from
machines that support G3 or Super G3)
Scanning method CCD flatbed scanning
Scanning resolution
(Supports ITU-T standards)
8 x 3.85 lines/mm (Standard)
8 x 7.7 lines/mm (Fine, Fine + Halftone)
8 x 15.4 lines/mm (Super Fine, Super Fine + Halftone)
16 x 15.4 lines/mm (Ultra Fine, Ultra Fine + Halftone)
Recording method Laser, electrostatic charge method
Transmission speed 33.6 kbps 2.4 kbps Automatic fallback
Transmission time*1 2 seconds (Super G3 mode / 33.6 kbps, JBIG), 6 seconds (G3 ECM mode
/ 14.4 kbps, MMR)
Paper sizes 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2", A4, A4R
Effective print width 11" max. (11" x 17" printing)
Input document size 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2", A4, A4R
(5-1/2" x 8-1/2": Vertically-oriented feeding),
Originals up to 39.3" (1000 mm) in length*
3
(using the RSPF);
* Refer to pages 15 for transmission of 5-1/2" x 8-1/2" size documents.
Effective scanning width 11.7" maximum
Halftone transmission Yes (256 levels)
Contrast adjustment Automatic (manual; five levels)
Extension telephone connection Possible (1 telephone)
Auto dialing Combined total of 500 rapid and group keys, redialing (automatic)
Timer transmission Yes
Program function Yes (8 programs)
F-code support Yes (can transmit and receive SUB/SEP (sub-address) and SID/PWD
(passcode) signals)
Automatic document feeding Yes (100 pages)
Image memory 2 MB*2
Error Correction Mode (ECM) Yes
Some discrepancies may exist in the illustrations and content due to improvements to the machine.
