NOZZLE PERFORMANCE CHART #1
SMITHCO NOZZLE PERFORMANCE CHART #1
Nozzle Type: XR Teejet & DG Teejet
Spacing: 20 inch (51cm)
Calibration: US Gal/Acre (GPA) & US Gal/1,000 Square Feet (GPT)
Pressure
Nozzle
Capacity
Application Rate GPA
Speed MPH (KPH)
Application Rate GPT
Speed MPH (KPH)
Color Size psi (Gal/Min) 2 (3) 3 (5) 4 (6) 5 (8) 2 (3) 3 (5) 4 (6) 5 (8)
Orange XR8001 20 (1.4) 0.07 10.4 6.9 5.2 4.2 0.24 0.16 0.12 0.10
30 (2.1) 0.09 13.4 9 7 5 0.31 0.21 0.16 0.11
40 (2.9) 0.10 14.9 10 8 6 0.34 0.23 0.17 0.14
60 (4.3) 0.12 17.8 12 9 7 0.41 0.28 0.21 0.16
Green XR80015 20 (1.4) 0.11 16.3 9 8 7 0.38 0.25 0.19 0.15
DG8002 30 (2.1) 0.13 19.3 13 10 8 0.44 0.30 0.22 0.18
40 (2.9) 0.15 22 15 11 9 0.51 0.34 0.26 0.20
60 (4.3) 0.18 27 18 13 11 0.61 0.41 0.31 0.25
Yellow XR8002 20 (1.4) 0.14 21 14 10 8 0.48 0.32 0.24 0.19
DG8002 30 (2.1) 0.17 25 17 13 10 0.58 0.39 0.29 0.23
40 (2.9) 0.30 45 30 22 18 1.02 0.68 0.51 0.41
60 (4.3) 0.37 55 37 27 22 1.26 0.84 0.63 0.50
Blue XR8003 20 (1.4) 0.21 31 21 16 13 0.72 0.48 0.36 0.29
DG8003 30 (2.1) 0.26 39 26 19 15 0.89 0.59 0.44 0.35
40 (2.9) 0.30 45 30 22 18 1.02 0.68 0.51 0.41
60 (4.3) 0.37 55 37 27 22 1.26 0.84 0.63 0.50
Red XR8004 20 (1.4) 0.28 42 28 21 17 0.98 0.64 0.48 0.38
DG8004 30 (2.1) 0.35 52 35 26 21 1.20 0.80 0.60 0.48
40 (2.9) 0.40 59 40 30 24 1.40 0.91 0.68 0.55
60 (4.3) 0.49 73 49 36 29 1.70 1.10 0.84 0.67
Brown XR8005 20 (1.4) 0.35 52 35 26 21 1.70 0.80 0.60 0.48
DG8005 30 (2.1) 0.43 64 43 32 26 1.50 0.98 0.73 0.59
40 (2.9) 0.50 74 50 37 30 1.70 1.10 0.85 0.68
60 (4.3) 0.61 91 60 45 36 2.10 1.40 1.00 0.83
Gray XR8006 20 (1.4) 0.42 62 42 31 25 1.40 1.00 0.72 0.57
30 (2.1) 0.52 77 51 39 31 1.80 1.20 0.89 0.71
40 (2.9) 0.60 89 59 45 35 2.00 1.40 1.00 0.82
60 (4.3) 0.73 110 73 55 44 2.50 1.70 1.30 1.00
White XR8008 20 (1.4) 0.57 85 56 42 34 1.90 1.30 0.97 0.78
30 (2.1) 0.69 102 68 51 41 2.40 1.60 1.20 0.94
40 (2.9) 0.80 119 79 59 48 2.70 1.80 1.40 1.10
60 (4.3) 0.98 146 97 73 58 3.30 2.20 1.70 1.30
Steel SS8010 40 (2.9) 1.00 144 96 72 54 3.30 2.20 1.70 1.20
60 (4.3) 1.20 180 120 90 78 4.10 2.80 2.00 1.80
