16 AMPLIFIERS
GM-D510M
Push an explosive 1000 watts of power into a hard-driving 2-ohm load. Class D design means high
efficiency, cool operation and high decibel sound without taking up too much space in your trunk—
perfect for driving a sub or two.
GM-5000T
Give your system good, clean MOSFET power. This amp has two channels to enhance your front or
rear sound, but they can be bridged together to drive a power-hungry subwoofer to the extreme.
GM-3000T
Experience the extra power that brings the clarity and impact of a live performance to your drive.
That’s what MOSFET power and advanced circuitry do to your music.
GM-6000F
Give your sound system an extra dose of power with 480 watts and MOSFET. It’s a smart, simple
solution to improving your sound. Variable LPF and HPF make it easy to upgrade your system.
GM-4000F
Take advantage of the pure, clean power that comes only from MOSFETs. Dynamic power can be
yours to enjoy whether the amp is configured for 2-channel or 4-channel.
SPECIFICATIONS
Peak Music Power
600W (4 ohms)/
760W 200W 480W 300W
1000W (2 ohms)
Number of Channels 1 2 2 4 4
Continuous Power (4 ohms) 300W x 1 125W x 2 40W x 2 50W x 4 35W x 4
Continuous Power (2 ohms) 500W x 1 190W x 2 50W x 2 60W x 4 40W x 4
Continuous Power Bridged (4 ohms)
380W x 1 100W x 1 120W x 2 70W x 2
Frequency Response (0, -1dB)
5Hz - 240Hz (+0.5, -3dB)
10Hz - 50kHz 10Hz - 45kHz 10Hz - 50kHz 10Hz - 50kHz
Total Harmonic Distortion (1kHz, 4 ohms)
0.1% (100Hz, 4 ohms)
0.008% 0.008% 0.008% 0.008%
Signal-to-Noise Ratio (IHF-A Weighted, at 1kHz)
100dB 100dB 100dB 95dB 100dB
Dimensions
10-9/16" x 2-1/16" x 11-3/4" x 2-3/8" x 11-3/4" x 2-3/8" x 11-3/4" x 2-3/8" x 11-3/4" x 2-3/8" x
9-13/16" 12-3/4" 6-1/8" 12-3/4" 9-3/8"
FEATURES
Bridgeable 1/2/3-Channel Capability
xx
Bridgeable 2/3/4-Channel Capability
xx
Class-D Amplifier x
PWM Regulated MOSFET Power Supply
xxxxx
MOSFET Output Section x
Balanced Isolator Input Circuit x x x x
Oversized Screw-Type Power/Ground Terminals
xxxxx
RCA Inputs 2 Ch 2 Ch 2 Ch 4 Ch 4 Ch
RCA Outputs (Pass Thru) x x
Speaker Level Input 2 Ch 4 Ch
Screw-Type Speaker Terminals x x x x x
Hi-Volt Input Level Control (200mV-6.5V)
x 400mV-6.5V 400mV-6.5V 400mV-6.5V
Variable Crossover (40-240Hz, -24dB/Oct. [LPF])
x
Variable LPF & HPF (40-120Hz, -12dB/Oct.)
x
Selectable LPF (80Hz, -12dB/Oct.) x x
Selectable LPF & HPF (80Hz, -12dB/Oct.)
x
GM-D510M GM-5000T GM-3000T GM-6000F GM-4000F
Class D Amplifier
Big, efficient power. Operating in Class D,
the space-saving GM-D510M gives you
massive power with less heat—and less
distortion—than with a conventional amp.
RCA Inputs and Outputs Oversized Power Ground Terminals
NEW FOR 2004 NEW FOR 2004
NEW FOR 2004NEW FOR 2004
760W MAX.
NEW FOR 2004
200W MAX.
1000W MAX. 480W MAX.
300W MAX.
