C2SBA+II/C2SBA+/C2SBA/C2SBE User’s Manual
Onboard I/O
• Built in ICH9 SATA Controller, 4 connectors for 4 devices (For the C2SBA+/
C2SBA/C2SBE)
• Built in ICH9R SATA Controller, 6 connectors for 6 devices (For the C2SBA+II)
• 1 oppy port interface (up to 2.88 MB)
• 1 Fast UART 16550 compatible serial port/header
• Intel 82566 Gigabit Ethernet Controller
• PS/2 mouse and PS/2 keyboard ports
• ITE-8212 IDE controller or ITE-8211 IDE controller (for PCB Rev. 1.2a and above)
supports two IDE hard drives (for the C2SBA+II/C2SBA+ only)
• Up to 12 USB (Universal Serial Bus) 2.0 ports for a speed of up to 480Mbps
• Realtek ALC 883 7.1 Channel High Denition Audio (HDA) codec supports 10
DAC Channels
• Built-in GMCH and onboard VGA connector (Not available on C2SBE)
Other
• Trusted Platform Module (TPM) 1.2 support (For the C2SBA/C2SBA+II/C2SBA+
only)
• Wake-on-LAN
• Wake-on-Ring (WOR)
• System Bus Clock Frequency Selection (Overclocking) Support (Note)
• Suspend-to-RAM
• Onboard +3V Standby Power Warning LED ("LE1")
• Pb Free
CD Utilities
• BIOS ash upgrade utility
• Drivers and software for Intel G33/P35 chipset utilities
Dimensions
• ATX form factor, 12.0" x 9.6" (304.8 x 243.8 mm)
