RD890 Confi guration
PCI Express Confi guration
Port Features
This submenu allows you to set the features for Ports 02 through 13 in
the system. Each port submenu allows you to defi ne the same settings
below.
Gen 2 High Speed Mode
This setting allows you to set the Gen 2 high-speed mode. Options
include Auto, Disabled, Software Initiated and Advertised RC.
Link ASPM
Use this setting to confi gure the Link ASPM. Options include Dis-
abled, L0s, L1, L0s & L1, L0 Downstream and L0 Downstream
+ L1.
Link Width
Use this setting to confi gure the Link Width. Options include Auto, x1,
x2, x4, x8 and x16.
Slot Power Limit, W
Use this setting to confi gure the Slot Power Limit power. The user can
adjust this value using the + and - keys. The default is 75.
Compliance Mode
This setting allows you to Enable or Disable the Compliance Mode.
Remap Port Device Number
This setting allows you remap the Port Device number. Options include
Auto and port numbers between 2 and 13.
L1 Immediate ACK
This setting allows you to Enable or Disable L1 ACK. When enabled,
the L1 will be ACK'd immediately.
Lane Reversal
Use this setting to Enable or Disable Lane Reversal.
