Chapter 1: Introduction
1-7
Introduction
Motherboard Features
CPU
• Single or dual Intel
®
Pentium
TM
III FCPGA 500 MHz-1.26+ GHz proces-
sors (including low power Pentium
TM
III processors) at Front Side
(system) Bus speeds of 133/100/66 MHz
Note: Please refer to the support section of our web site for a complete list of supported
processors. You must use the server version of the processors mentioned above.
Memory
• Four DIMM sockets to support up to 4 GB PC1600 or PC2100 DDR-RAM
Chipset
• VIA Apollo Pro 266T
Expansion Slots
• Three (3) 32-bit PCI (33 MHz)
BIOS
• 4 Mb Award
®
Flash ROM
• ACPI/APM Power Management
• PAC'99 color-coded I/O connectors
• One WOL (Wake-On-LAN) connector
• One WOM (Wake-On-Modem) connector
• Internal control of Power-On Mode for recovery from AC power loss
PC Health Monitoring
• Seven onboard voltage monitors for CPU core, chipset voltage, +3.3V,
±5V and ±12V
• Four-fan status monitor with firmware/software on/off control
• Environmental temperature monitor and control
• CPU fan auto-off in sleep mode
• Power-up mode control for recovery from AC power loss
• System overheat LED and control
• System resource alert
• Hardware BIOS virus protection
• Auto-switching voltage regulator for the CPU cores
• Slow blinking LED for suspend state indicator
• BIOS support for USB keyboard
