X7DB8/X7DBE User's Manual
Figure 1-2. X7DB8/X7DBE Motherboard Layout
1. Jumpers not indicated are for test purposes only.
2. See Chapter 2 for detailed information on jumpers, I/O ports and
JF1 front panel connections.
3. " " indicates the location of Pin 1.
4. SCSI is for the X7DB8 only.
5. SEPC: Supermicro Enhanced Power Connector, specially designed
to support Supermicro 2U Riser Card only.
6. When LE1 is on, make sure to turn off the power before removing or installing
components.
7. For the ZCR card to function properly, be sure to install it in the green slot.
(not drawn to scale)
