Chapter 1: Introduction
1-7
Chassis intrusion detection
System resource alert via Supero Doctor III
ACPI Features
Slow blinking LED for suspend state indicator
Main switch override mechanism
ACPI Power Management
Power-on mode for power recovery
Onboard I/O
Six SATA ports support RAID 0, 1, 10 and 5 (in the Windows OS environ-
ment)
Eight SAS ports supports RAID 0, 1, 10 and 5. (For X7DCL-3 only)
• One SIMLC IPMI 2.0 socket
Intel 82573V and 82573L LAN chips support two Giga-bit LAN ports
One EIDE Ultra DMA/100 bus master interface
One oppy port interface
Two COM ports(1 header, 1 port)
Up to six USB 2.0 (Universal Serial Bus) (2 ports, 4 Headers)
• XGI Volari Z9s 32 MB Graphic Controller
• Super I/O: Winbond W83627HG
Other
External modem ring-on
Wake-on-LAN (WOL)
Wake-on-Ring (WOR)
Console redirection
Onboard Fan Speed Control by Thermal Management via BIOS
CD/Diskette Utilities
Device drivers and Software
Dimensions
ATX 12.05" x 10" (306.1mm x 254 mm)
