Chapter 2: Installation
2-29
A. Power LED
Onboard PWR LED Indicator (LE1)
LED Color Defi nition
Off System Off
On Standby Power On
Green System On
Onboard Power LED (LE1)
The Onboard 3.3V Standby Power
LED is located at LE1 on the moth-
erboard. When LE1 is off, the
system is off. When the LED is on,
the power is on. Unplug the power
cable before removing or installing
components. See the layout below
for the LED location.
A
