Chapter 1: Introduction
1-7
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Keyboard Wakeup from Soft-off •
Onboard I/O
Intel ICH10R supports six SATA ports (RAID0, RAID1, RAID10, RAID5 supported •
in the Windows OS Environment and RAID 0, RAID 1, RAID 10 supported by
the Linux OS)
Winbond WPCM450 BMC (Baseboard Management Controller) supports IPMI
•
2.0 with KVM support
Intel 82576 Dual-LAN Gigabit Ethernet Controller supports dual Giga-bit LAN
•
ports
Onboard PHY Chip supports IPMI dedicated LAN
•
One COM port•
Up to four USB 2.0 (Universal Serial Bus) connections (2 Ports and 2 Front •
Headers)
Super I/O: Winbond W83527HG
•
Other
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Proprietary 16.64" (L) x 7.71" (W) (422.66 mm x 195.83 mm)•
