X8DTU-LN4F+ Motherboard User’s Manual
Peripheral
Devices
USB Devices
Two (2) USB ports on the rear I/O panel (USB 0/1)
•
One (1) USB connection for front access (USB 6) •
One (1) Internal USB connection (USB 7)•
Two (2) Type A internal connector (USB 2/3, 4/5)•
BIOS
32 Mb SPI AMI BIOS•
®
SM Flash BIOS
APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
•
Plug & Play (PnP) and SMBIOS 2.5
Power
ACPI Power Management•
Confi g.
Main switch override mechanism•
Keyboard Wake-up from Soft-Off•
Internal/External modem ring-on•
Power-on mode for AC power recovery•
PC Health
CPU Monitoring
Monitoring
CPU1 Vcore, CPU2 Vcore, CPU1 DIMM, CPU2 •
DIMM, 1.1V, 3.3V, 1.5V, +5V, +12V, 3.3V Standby,
5V Standby, and Vbat.
CPU 6-Phase switching voltage regulator per CPU
•
CPU/System overheat LED and control•
CPU Thermal Trip support•
Thermal Monitor 2 (TM2) support•
Fan Control
Fan status monitoring with fi rmware 4-pin (Pulse
•
Width Modulation) fan speed control
Low noise fan speed control
•
System
Management
PECI (Platform Environment Confi guration Interface) •
2.0 support
System resource alert via Supero Doctor III
•
SuperoDoctor III, Watch Dog, NMI•
Chassis Intrusion Header and Detection•
Dimensions
14.85" (L) x 12.68" (W) (377.19 mm x 322.07 mm)•
Note: For IPMI Confi guration Instructions, please refer to the Embedded
IPMI Confi guration User's Guide available @ http://www.supermicro.com/
support/manuals/.
