X8SIA/X8SIA-F User’s Manual
Serial (COM) Ports
Two (2) Fast UART 16550 Connections: one 9-pin RS-232
port and one header
Super I/O
Winbond Super I/O W83627DHG UBE
BIOS 32 Mb SPI AMI BIOS
®
SM Flash BIOS
DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard and
SMBIOS 2.5
PowerConguration ACPI/ACPM Power Management
Main switch override mechanism
Wake on LAN Header
Keyboard Wake-up from Soft-Off
Internal/External modem ring-on
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for CPU core, +3.3V, +5V,
+/-12V, +3.3V Stdby, VBAT, Memory, Chipset
CPU 5-Phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
Fan Control
Fan status monitoring with rmware (Pulse Width Modula-
tion), Low-noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 2.0
support
System resource alert via Supero Doctor III
SuperoDoctor III, Watch Dog, NMI
Chassis Intrusion Header and Detection
iSCSI Internet Protocol support
CD Utilities BIOS ash upgrade utility
Drivers and Intel® 3420 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
Dimensions ATX form factor, 12" x 9.6"
Note: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
