Hot Plug
Set this item to Enabled to enable hot-plugging. The options are
Enabled and Disabled.
Staggered Spin-Up
Set this item to Enabled to enable Staggered Spin-up support. The
options are Enabled and Disabled.
RAID
The following items are displayed when RAID Mode is selected:
SATA Port0~Port5
This item displays the information detected on the installed SATA drives
on the particular SATA port.
Hot Plug
Set this item to Enabled to enable hot-plugging. The options are
Enabled and Disabled.
PCIe/PCI/PnP Conguration
This feature allows the user to set the PCI/PnP congurations for the following items:
PCI Latency Timer
This feature sets the latency Timer of each PCI device installed on a PCI bus. Select
64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96, 128,
160, 192, 224 and 248.
Above 4G Decoding
This feature enables or disables 64-bit capable devices to be decoded above the
4GB address space (if the system supports 64-bit PCI decoding). The options are
Enabled and Disabled.
Onboard LAN Option ROM Select
This feature selects whether to load the iSCSI or PXE onboard LAN option ROM.
The options are iSCSI and PXE.
Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM
This feature is to enable or disable the onboard option ROMs. The default for LAN1
is Enabled. The default for LAN2 is Disabled.
