Installation Drawings
25
Figure 18 Ground strap location for connected cabinets
Reference of corner post
of connected cabinets
Cabinet-to-Cabinet
Bolting Instructions
Typical Ground Strap Installation
FRONT SIDE OF
UNITS
(Use for all connected units except Battery Cabinet)
A
DETAIL A
