Table 11 Recommended conduit and cable sizes—Module Bypass Input
UPS
Rating System Input Voltage (VAC)
Module Bypass Input
Nominal Selection Alternate Selection
kVA kW Rectifier Bypass
Maint
Byp Output
Top Cable Entry
Wire & Conduit
Ph, N, G,THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G, THW / RNC
Top Cable Entry
Wire & Conduit
Ph, N, G, THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G THW / RNC
250 225 480 480 480 480
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 2C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
(3) 2.5C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
300 270 480 480 480 480
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
400 360 480 480 480 480
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
500 450 480 480 480 480
(3) 3.5C 3-500kcmil,
2-250kcmil , #1/0AWG
(3) 4C 3-500kcmil,
2-250kcmil , #1/0AWG
(4) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
(3) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
Table 12 Recommended conduit and cable sizes—Module Output
UPS
Rating
System
Input Voltage (VAC)
Module Output
Nominal Selection Alternate Selection
kVA kW Rectifier Bypass
Maint
Byp Output
Top Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G THW / RNC
Top Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G THW / RNC
250 225 480 480 480 480
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 2C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
(3) 2.5C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
300 270 480 480 480 480
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
400 360 480 480 480 480
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
500 450 480 480 480 480
(3) 3.5C 3-500kcmil,
2-250kcmil , #1/0AWG
(3) 4C 3-500kcmil,
2-250kcmil , #1/0AWG
(4) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
(4) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
Table 13 Recommended conduit and cable sizes—Load Output
UPS Rating System Input Voltage (VAC)
Load Output
Nominal Selection Alternate Selection
kVA kW Rectifier Bypass
Maint
Byp Output
Top Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
Top Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
Bottom Cable Entry
Wire & Conduit
Ph, N, G THW / FMC
250 225 480 480 480 480
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(2) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 2C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
(3) 2.5C 3-#2/0AWG,
2-#2/0AWG, #1/0AWG
300 270 480 480 480 480
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(2) 3.5C 3-350kcmil,
2-350kcmil, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
(3) 3C 3-#4/0AWG,
2-#4/0AWG, #1/0AWG
400 360 480 480 480 480
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(2) 4C 3-500kcmil,
2-500kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
(3) 3C 3-250kcmil,
2-250kcmil, #1/0AWG
500 450 480 480 480 480
(3) 3.5C 3-500kcmil,
2-250kcmil , #1/0AWG
(3) 4C 3-500kcmil,
2-250kcmil , #1/0AWG
(4) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
(4) 3C 3-250kcmil,
2-#4/0AWG, #1/0AWG
Table 14 Recommended conduit and cable sizes—Load Bank Output
UPS Rating System Input Voltage, VAC Load Bank Output
kVA kW Rectifier Bypass Maint Byp Output
Nominal Selection
Front Cable Entry
Wire-3W + GND
250 225 480 480 480 480 (1) 3-500kcmil, #1/0AWG
300 270 480 480 480 480 (2) 3-#4/0AWG, #1/0AWG
400 360 480 480 480 480 (2) 3-350kcmil, #1/0AWG
500 450 480 480 480 480 (2) 3-500kcmil, #1/0AWG
