PARTS LIST
ITEM NO. PART NO. dESCRIPTION QTY
1 349011635 Foam grip 1
2 331011635 Upper handle 1
3 311201635 Gun holder assy 1
4 322011628 Screw ST5.5*22-F 4
5 311211635 Spray tip panel assy 1
6 34139319 25 degree nozzle 1
7 31225363 40 degree nozzle 1
8 31240363 Soap nozzle 1
9 31208363 Turbo Nozzle 1
10 341111635 Cord arm basement 1
11 341101635 Cord arm 1
12 32913847 Washer 1
13 322021635 Screw M6*35 1
14 311001635 Power cord assy 1
15 341401628 Switch knob 1
16 322031635 Screw ST4.2*16-F 8
17 341011635 Upper housing 1
18 341171635 Heat isolation board 1
19 33306847 Spring button 2
20 332021635 Water outlet connector 1
21 34202368 O-ring 1
22 32202368 Screw ST4.2*16-F 2
23 341201635 Water outlet connecotr press plate 1
24 31101363A Motor pump assy 1
25 33302365 U pin 2
26 311221635 Water inlet connector assy 1
27 322011635 Bolt M6*20 10
28 341371635 Hose reel bracket 2
29 322011023 Bolt M6*50 4
30 329011635 Washer 4
31 341021635 Lower housing 1
32 331021635 Main frame 1
33 32222301A Bolt M6 nut 4
34 32233301A Washer 4
