LSI2108/2208SASMegaRAIDCongurationUtilityUser'sManual
2-10
3. Select one of the following conguration methods:
•Manual Conguration: Check this item to manually create drive groups and
virtual drives and manually set their parameters. All drives including congured
drives will display.
•Automatic Conguration: Check this item to allow the LSI SAS RAID Controller
to congure the MegaRAID settings automatically.
- Select a Redundancy option for Automatic Conguration. Select Redundancy
When Possible to congure RAID 1 for systems with only two drives or congure
RAID 5 or RAID 6 if the system has three or more drives. Select No Redundancy
to congure all drives as RAID 0 virtual drives.
- Select whether to enable or disable Data Protection.
Note: RAID 10, 50, and 60 cannot be automatically congured.
•Add Conguration: Check this item to keep the existing conguration settings
and to add new settings to the drive. This is a safe operation because there is
no risk of losing data.
After you have checked an item, select Next to proceed with the action or select
Cancel to return to the conguration utility main page.
AddingaConguration
If you selected Add Conguration, the following screen displays.
AddConguration
