1-3 Blade Module Features
Table 1-1 lists the main features of the SBI-7426T-S3 blade module. See the proceeding
section for components typically included in a blade system and other optional
components. Specific details on the SBI-7426T-S3 blade module is found in Chapter 4: "
Blade Module Features" on page 4-1.
Processors
The SBI-7426T-S3 blade module supports up to dual 1366-pin Intel Xeon 5500 series
processors.
Refer to the Supermicro web site for a complete listing of supported processors (http://
www.supermicro.com/products/superblade). Please note that you will need to check the
detailed specifications of a particular blade module for a list of the CPUs it supports.
Details on installation of the processor into the SBI-7426T-S3 blade module are found in
Chapter 3: "Setup and Installation" on page 3-1.
Memory
The SBI-7426T-S3 blade module has twelve 240-pin DIMM sockets that can support up
to 96 GB/24 GB of VLP ECC Registered/Unbuffered ECC DDR3-1333/1066/800
SDRAM. Memory is interleaved, which requires modules of the same size and speed to
be installed in groups (of two or three).
Please refer to the Supermicro web site for a list of supported memory
(www.supermicro.com/products/superblade). The detailed specifications for a blade
module will contain a link to a list of recommended memory sizes and manufacturers.
Details on installation of memory modules into the SBI-7426T-S3 blade module are
found in Chapter 3: "Setup and Installation" on page 3-1.
Table 1-1. SBI-7426T-S3 Blade Specification Features
Mainboard
B8DT6 (proprietary form factor)
Chassis Dimensions (HxWxD): 11.32” x 1.67” x 18.9”
Processors
Single or dual Intel
™
Xeon
®
5500 Sequence processors. Please refer to
our web site for a complete listing of supported processors.
FSB Speed QPI speed, up to 6.4 GT/s bus speed
Chipset Intel 5500 Tylersburg
Graphics Controller Hermon
BIOS 32 MB SPI Flash EEPROM wiht AMI
®
BIOS
Memory Capacity
Twelve 240-pin DIMM sockets supporting up to 96 GB/24 GB of VLP ECC
Registered/Unbuffered ECC DDR3-1333/1066/800 SDRAM.
Drive Controller LSI SAS2 on-board controller for three SAS2 or SATA disk drives
Hard Drive Bays Three (3) hot-swap drive bays for 2.5" SAS2 or SATA disk drives
