Table 6-12. MPS Configuration Sub-menu
Menu Option Description
MPS Revision
This option allows you to select the MPS revision used for your system. Options
include 1.1 and 1.4.
Table 6-13. PCI Express Configuration Sub-menu
Menu Option Description
Active State
Power-Management
This option allows you to enable/disable PCI Express L0s and L1 link power in
your system. Options include Enabled and D
ISABLED.
Table 6-14. SMBIOS Configuration Sub-menu
Menu Option Description
SMI Support
This option enables SMBIOS SMI Wrapper support for Plug-and-Play Func
50h-54h. Options include Enabled and D
ISABLED.
Table 6-15. Remote Access Configuration Sub-menu
Menu Option Description
Remote Access
This option allows you to select your remote access type. Options include COM1
and COM2.
Serial Port Number
This option allows you to select a serial port for console redirection if the
selected port is enabled. Options include COM1 and COM2.
The Base Address IRQ is displayed statically under this option for your
reference.
Serial Port Mode
Use this option to select the serial port mode setting. Options include 115200
8,n,1 / 57600 8,n,1 / 38400 8,n,1 / 19200 8,n,1 / 09600 8,n,1
Flow Control
This option allows you to select Flow Control for redirection. Options include
None, H
ARDWARE or SOFTWARE.
Redirection After
BIOS POST
This option allows you to specify redirection after BIOS POST. Options include
the following:
•D
ISABLE – Turns off the redirection after POST
•B
OOT LOADER – Redirection is active during Boot Loader
• Always – Redirection is always active.
NOTE: Some operating systems may not work if set to Always.
Terminal Type
This option allows you to select the Terminal Type for your system. Options
include ANSI, VT100 and VT-UTF8.
VT-UTF8 Combo Key
Support
Use this option to enable VT-UTF8 Combination Key support for ANSI/VT100
terminals. Options include Enabled and D
ISABLED.
Sredir Memory
Display Delay
This option gives the delay in seconds to display memory information. Options
include No Delay, D
ELAY IN 1 SEC, DELAY IN 2 SEC and DELAY IN 4 SEC.
