Tesla M2090 Dual-Slot Computing Processor Module BD-05766-001_v02 | 10
POWER SPECIFICATIONS
The Tesla M2090 requires power from the PCIe connector as well as one or two auxiliary
power connectors.
Table 4. Configuration with External PCI Express Connectors
8-Pin Power Connector
6-Pin Power
Connector Result
Connected
(either 8-pin or 6-pin)
Connected Valid configuration board will operate to
specification
8-pin connected Not connected Valid configuration board will operate to
specification
6-pin connected Not connected Insufficient power board will not operate
Not connected Connected Insufficient power board will not operate
Not connected Not connected Insufficient power board will not operate
Note: Detailed information about power draw by rail is available to authorized
system partners in the Tesla M2090 System Design Guide.
