Chapter 1: Introduction
1-9
USB Wake-up from Soft-Off•
Wake-on-LAN•
Power-on mode for AC power recovery•
PC Health Monitoring
CPU Monitoring
Onboard voltage monitors for CPU core, Memory Voltage, Chipset Voltage,
•
+1.8V, +3.3V, +3.3V standby, +5V, +5V, Standby, VBat and ±12V
CPU 6-Phase switching voltage regulator
•
CPU/System overheat LED and control•
CPU Thermal Trip support•
Thermal Monitor 2 (TM2) support•
Fan Control
Fan status monitoring with fi rmware 4-pin (Pulse Width Modulation) fan
•
speed control
Low noise fan speed control
•
System Management
PECI (Platform Environment Confi guration Interface) 2.0 support•
System resource alert via Supero Doctor III •
SuperoDoctor III, Watch Dog, NMI•
I•
2
C temperature sensing logic
Chassis Intrusion Header and Detection
•
Pb Free•
CD Utilities
BIOS fl ash upgrade utility•
Drivers and software for Intel® X58 Express chipset utilities •
Dimensions
ATX form factor, 12" x 9.6" (304.8 x 243.8 mm)•
