Chapter 1: Introduction
1-7
Onboard I/O
Adaptec AIC-9410W SAS Controller w/HostRAID support (RAID 0, 1,10)
Intel ESB-2 South Bridge supports 6 SATA connectors (w/RAID 0, 1, 5,10) (For
the Windows OS only)
• One SIM Low Profi le IPMI slot
Intel 82563EB Gigabit Dual-Port Ethernet controller
1 EIDE Ultra DMA/100 bus master interfaces w/2 devices supported
1 fl oppy port interface
1 serial port
1 EPP/ECP Parallel Port
• 7.1+2 Channel High Defi nition Audio Connection
• Super I/O: Winbond W83627HG w/Hardware Monitor support: W83793G
PS/2 mouse and PS/2 keyboard ports
Up to 6 USB 2.0 (Universal Serial Bus) (4 ports, 2 Headers)
• Super I/O
Other
• External modem ring-on
• Wake-on-LAN (WOL)
• Wake-on-Ring (WOR)
• Console redirection
Onboard Fan Speed Control by Thermal Management via BIOS
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers
Dimensions
Ext. ATX 12.08" x 13.05" (306.8 mmx 331.5 mm)
