Version 0506
CPN02433
DVI to HDMI
cable adapter
DVI to HDMI (High-Definition
Multimedia Interface) cable
adapter
CPN01491
Power Supply
wall-mount,
EU, 100-
240VAC,
5VDC, 2.4A
Power Supply wall-mount, EU,
100-240VAC, 5VDC, 2.4A (to be
used where PoE is not available)
CPN01503
Power Supply
wall-mount,
US, 100-
240VAC,
5VDC, 2.4A
Power Supply wall-mount, US,
100-240VAC, 5VDC, 2.4A (to be
used where PoE is not available)
CPN01504
Power Supply
wall-mount,
UK, 100-
240VAC,
5VDC, 2.4A
Power Supply wall-mount, UK,
100-240VAC, 5VDC, 2.4A (to be
used where PoE is not available)
CPN02163
Jack PC IDC
Termination
Kit
Jack PC IDC Termination Kit to
connect the Flex-Jack Housing to
the LAN/PoE infrastructure
CPN02165
Jack PC IDC
Termination
Kit with Strong
Location
Authentication
Jack PC IDC Termination Kit with
Strong Location Authentication to
connect the Flex-Jack Housing to
the LAN/PoE infrastructure.
Includes a dedicated chip for
Location Authentication to be used
together with Xcalibur Global
Management software - Please
contact Chip PC for availability
CPN02164
Jack PC RJ-
45
Termination
Kit
Jack PC RJ-45 Termination Kit to
connect the Flex-Jack Housing to
RJ-45 cable (length 150mm, 5.9
Inch) You can use this device for
evaluating the Jack PC by
connecting it to a local switch
using the connected RJ-45 cable.
Can also be used for
Network/Wiring troubleshooting.
CPN02166
Jack PC RJ-
45
Termination
Kit with Strong
Location
Authentication
Jack PC RJ-45 Termination Kit
with Strong Location
Authentication to connect the Flex-
Jack Housing to Flex-Jack
Housing to RJ-45 cable (length
150mm) You can use this device
for evaluating the Jack PC by
connecting it to a local switch
using the connected RJ-45 cable.
Can also be used for
Network/Wiring troubleshooting).
Includes a dedicated chip for
Location Authentication to be used
together with Xcalibur Global
Management software - Please
contact Chip PC for availability
