31
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
85 33203363 Reel pin 1
86 34124363 Reel shaft 1
87 34126363 Reel handle 1
88 34127363 Reel Nut 1
89 34113365 Ring 2
90 34108363 Handle 1
91 3220335 Screw 4
92 32202363 Bolt 2
93 32901363 Washer 2
94 33303365 Lower pull rod 1
95 34115363 Pull rod head 1
96 33202363 Upper pull rod 1
97 32201100 Lock Nut 2
98 33305365 Washer 2
99 33204365 Pull rod shaft 2
100 33205365 Nut 1
101 33207365 Pin 1
102 33901365 Pin spring 1
103 33206365 Pin
seat 1
104 34118365 Pin bushing 1
105 34119365 Pin cap 1
106 34120365 Wand Hook 1
107 34121365 Gun handle hook 1
108 3220108 Screw 2
109 32902363 Nut 2
110 32903363 Washer 4
111 34111363 Nozzle store 1
112 34203363 Nozzle bushing 4
113 32203363 Screw 2
114 31203363 40 degree nozzle 1
115 31204319 25 degree nozzle 1
116 31201363 0 degree nozzle 1
117 34112363 Gun holder 1
118 342
02363 Foam grip 1
119 31205319 Soap nozzle(75 degree nozzle) 1
120 31201365 Gun handle ASSY 1
121 31202365 Wand ASSY 1
122 31201301A Turbo nozzle 1
123 36511154A Junction cap 3
124 3030175 Heat-shrinkable tubing Φ6 5
