Chapter 1: Introduction
1-7
ACPI Features
Slow blinking LED for suspend state indicator•
BIOS support for USB keyboard •
Main switch override mechanism•
External modem ring-on•
Onboard I/O
Built in ICH10 SATA Controller, 6 connectors for up to 6 devices•
One fast UART 16550 compatible serial port•
Realtek RTL8111C Gigabit Ethernet controllers •
PS/2 mouse and PS/2 keyboard ports•
ITE 8213F Controller supports one IDE channel & two devices (C2SEA only) •
12 USB (Universal Serial Bus) 2.0 ports •
Realtek ALC 888 High-Defi nition Audio (HDA) codecs supports 10 DAC Chan-•
nels
Built-in GMCH and onboard VGA Connector
•
High-Defi nition Multimedia Interface (HDMI) Connector (C2SEA only)•
Two IEEE 1394a Headers (C2SEA only)•
Other
Wake-on-LAN (WOL)•
Wake-on-Ring (WOR)•
System Bus Clock Frequency Selection (Overclocking) Support •
Suspend-to-RAM•
Onboard +5V Standby Power Warning LED ("LE1")•
CD Utilities
BIOS fl ash upgrade utility•
Drivers and software for Intel G45/G43 Express chipset utilities •
Dimensions
ATX form factor, 12.0" x 9.6" (304.8 x 243.8 mm)•
Overclocking Considerations
Please be aware of the following conditions when "overclocking" is used: Setting
a high CPU FSB Speed (overclocking), DRAM Frequency or selecting a high CPU
V-Core voltage, memory voltage, chipset voltage, ICH chipset voltage, or the FSB
termination voltage may result in system instability. If this occurs, revert the setting
to the default setting. In addition, extra fans may be needed for proper system cool-
ing. The C2SEA/C2SEE offers the option of "overclocking"; however, Supermicro is
not responsible for any damage caused by the use of overclocking.
