IDE Channel 0 Master/Slave and IDE Secondary Master/Slave
These settings allow the user to set the parameters of the slots specifi ed. Press
<Enter> to activate the following submenu items for detailed options. Set the
correct confi gurations accordingly.
Type
This item allows you to select the type of IDE hard drive. Select Auto to allow
the BIOS to automatically set the HDD's capacity, number of heads, etc. Enter a
number from 1-39 to select a type of hard drive. Select User to allow the user to
enter the parameters of the HDD installed at this connection. Select CDROM if a
CDROM drive is installed. Select ATAPI if a removable disk drive is installed.
Multi-Sector Transfers
This item allows the user to specify the number of sectors per block to be
used in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors,
and 16 Sectors.
LBA Mode Control
This item determines whether the Phoenix BIOS will access the IDE Channel 0
Master Device via the LBA mode. The options are Enabled and Disabled.
32 Bit I/O
This option allows the user to enable or disable the function of 32-bit data transfer.
The options are Enabled and Disabled.
Transfer Mode
This option allows the user to set the transfer mode. The options are Standard,
Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.
Ultra DMA Mode
This option allows the user to select Ultra DMA Mode. The options are Disabled,
Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.
Parallel ATA
This setting allows the user to enable or disable the function of Parallel ATA. The
options are Disabled, and Enabled.
Serial ATA
This setting allows the user to enable or disable the function of Serial ATA. The
options are Disabled and Enabled.
