4-4
X8DA3/X8DAi User’s Manual
4-3 Advanced Setup Confi gurations
Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu
items:
XBOOT Features
Quick Boot
If Enabled, this option will skip certain tests during POST to reduce the time needed
for system boot. The options are Enabled and Disabled.
Quiet Boot
This option allows the bootup screen options to be modifi ed between POST mes-
sages or the OEM logo. Select Disabled to display the POST messages. Select
Enabled to display the OEM logo instead of the normal POST messages. The op-
tions are Enabled and Disabled.
AddOn ROM Display Mode
This sets the display mode for the Option ROM. Select Keep Current to use the cur-
rent AddOn ROM Display setting. Select Force BIOS to use the Option ROM display
mode set by the system BIOS. The options are Force BIOS and Keep Current.
Bootup Num-Lock
This feature selects the Power-on state for Numlock key. The options are Off
and On.
Wait For 'F1' If Error
This forces the system to wait until the 'F1' key is pressed if an error occurs. The
options are Disabled and Enabled.
BIOS SETUP UTILITY
Main Advanced
Security
Boot
Exit
vXX.XX (C) Copyright 1985-2009, American Megatrends, Inc.
Advanced Settings
WARNING: Setting the wrong values in the sections below
may cause the system to malfunction.
Boot Features
Processor & Clock Options
Advanced Chipset Control
IDE/SATA Configuration
PCI/PnP Configuration
Super IO Device Configuration
Remote Access Configuration
System Health Monitor
ACPI Configuration
Trusted Computing
DMI Event Logging
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Select Boot Features
