X9DRG-HF/X9DRG-HTF Motherboard User’s Manual
I/O Devices
SATA Connections
•SATA Ports Two (2): SATA 3.0 Ports (I-
SATA1~I-SATA2)
Four (4) SATA 2.0 Ports (I-
SATA2~5) (from AHCI)
Four (4) SATA 2.0 Ports (S-
SATA0~3) (from SCU: Storage
Control Unit)
•RAID RAID 0, 1, 5, 10
IPMI 2.0
•IPMI 2.0 supported by the Nuvoton WPCM450R
BMC
Serial (COM) Port
•One (1) Fast UART 16550 Connection: 9-pin RS-
232 port
Super I/O
•Winbond Super I/O 83527
Peripheral
Devices
USB Devices
•Two (2) USB ports on the rear I/O panel (USB 0/1),
BIOS
•16MB SPI AMI BIOS
®
SM Flash BIOS
•APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.5
Power
•ACPI/ACPM Power Management
Management
•Main switch override mechanism
•Keyboard Wake-up from Soft-Off
•Power-on mode for AC power recovery
•Intel
®
Intelligent Power Node Manager
•Management Engine
PC Health
CPU Monitoring
Monitoring
•Onboard voltage monitors for 1.8V, +3.3V, 3.3VSB,
+5V Standby, 1.35V, 1.5V, Chipset Voltage, and
Battery Voltage.
•CPU 6-Phase switching voltage regulator
•CPU/System overheat LED and control
•CPU Thermal Trip support
•Thermal Monitor 2 (TM2) support
