4-18

X9DRG-HF/X9DRG-HTF Motherboard User’s Manual

SuperIOConguration

Super IO Chip: This item displays the Super IO chip used in the motherboard.

SerialPort1Conguration

Serial Port

Select Enabled to enable a serial port specied by the user. The options are En-

abled and Disabled.

Device Settings

This item displays the settings of Serial Port 1.

Change Settings

Use this feature to set the optimal Platform Environment Control Interface (PECI)

setting for a serial port specied. The default setting is Auto, which will allow the

AMI BIOS to automatically select the best PECI setting.

Device Mode

Use this feature to select the desired mode for a serial port specied. The options

are Normal and High Speed.

SOLConguration

Serial Port

Select Enabled to enable a serial port specied by the user. The options are En-

abled and Disabled.

Device Settings

This item displays the settings of the SOL Port.

Change Settings

Use this feature to set the optimal Platform Environment Control Interface (PECI)

setting for a serial port specied. The default setting is Auto, which will allow the

AMI BIOS to automatically select the best PECI setting.

Serial Port Attribute

Use this feature to select the attribute for this serial port. The options are SOL

(Serial On LAN), and COM.
